The Harvester team is pleased to announce the next release of our open source hyperconverged infrastructure product. For those unfamiliar with how Harvester works, I invite you to check out this blog from our 1.0 launch that explains it further. This next version of Harvester adds several new and important features to help our users get more value out of Harvester. It reflects the efforts of many people, both at SUSE and in the open source community, who have contributed to the product thus far. Let’s dive into some of the key features.

GPU and PCI device pass-through

The GPU and PCI device pass-through experimental features are some of the most requested features this year and are officially live. These features enable Harvester users to run applications in VMs that need to take advantage of PCI devices on the physical host. Most notably, GPUs are an ever-increasing use case to support the growing demand for Machine Learning, Artificial Intelligence and analytics workloads. Our users have learned that both container and VM workloads need to access GPUs to power their businesses. This feature also can support a variety of other use cases that need PCI; for instance, SR-IOV-enabled Network Interface Cards can expose virtual functions as PCI devices, which Harvester can then attach to VMs. In the future, we plan to extend this function to support advanced forms of device passthrough, such as vGPU technologies.

VM Import Operator

Many Harvester users maintain other HCI solutions with a various array of VM workloads. And for some of these use cases, they want to migrate these VMs to Harvester. To make this process easier, we created the VM Import Operator, which automates the migration of VMs from existing HCI to Harvester. It currently supports two popular flavors: OpenStack and VMware vSphere. The operator will connect to either of those systems and copy the virtual disk data for each VM to Harvester’s datastore. Then it will translate the metadata that configures the VM to the comparable settings in Harvester.

Storage network

Harvester runs on various hardware profiles, some clusters being more compute-optimized and others optimized for storage performance. In the case of workloads needing high-performance storage, one way to increase efficiency is to dedicate a network to storage replication. For this reason, we created the Storage Network feature. A dedicated storage network removes I/O contention between workload traffic (pod-to-pod communication, VM-to-VM, etc.) and the storage traffic, which is latency sensitive. Additionally, higher capacity network interfaces can be procured for storage, such as 40 or 100 GB Ethernet.

Storage tiering

When supporting workloads requiring different types of storage, it is important to be able to define classes or tiers of storage that a user can choose from when provisioning a VM. Tiers can be labeled with convenient terms such as “fast” or “archival” to make them user-friendly. In turn, the administrator can then map those storage tiers to specific disks on the bare metal system. Both node and disk label selectors define the mapping, so a user can specify a unique combination of nodes and disks on those nodes that should be used to back a storage tier. Some of our Harvester users want to use this feature to utilize slower magnetic storage technologies for parts of the application where IOPS is not a concern and low-cost storage is preferred.

In summary, the past year has been an important chapter in the evolution of Harvester. As we look to the future, we expect to see more features and enhancements in store. Harvester plans to have two feature releases next year, allowing for a more rapid iteration of the ideas in our roadmap. You can download the latest version of Harvester on Github. Please continue to share your feedback with us through our community slack or your SUSE account representative.

Learn more

Download our FREE eBook, 6 Reasons Why Harvester Accelerates IT Modernization Initiatives. This eBook identifies the top drivers of IT modernization, outlines an IT modernization framework and introduces Harvester, an open, interoperable hyperconverged infrastructure (HCI) solution.

Today, automation and configuration management tools are critical for operation teams in IT. Infrastructure as Code (IaC) is the way to go for both Kubernetes and more traditional infrastructure. IaC mixes the great capabilities of these tools with the excellent control and flexibility that git offers to developers. In such a landscape, tools like Ansible, Salt, or Terraform become a facilitator for operations teams since they can manage cloud native infrastructure and traditional infrastructure using the IaC paradigm.

Harvester is an HCI solution based on Linux, KubeVirt, Kubernetes and Longhorn. It mixes the cloud native and traditional infrastructure worlds, providing virtualization inside Kubernetes, which eases the integration of containerized workloads and VMs. Harvester can benefit from IaC using tools like Terraform or, since it is based in Kubernetes, using methodologies such as GitOps with solutions like Fleet or ArgoCD. In this post, we will focus on the Terraform provider for Harvester and how to manage Harvester with Terraform.

If you are unfamiliar with Harvester and want to know the basics of setting up a lab, read this blog post: Getting Hands-on with Harvester HCI.

Environment setup

To help you follow this post, I built a code repository on GitHub where you can find all that is needed to start using the Harvester Terraform provider. Let’s start with what’s required: a Harvester cluster and a KubeConfig file, along with a Terraform CLI installed on your computer, and finally, a git CLI. In the git repo, you can find all the links and information needed to install all the software and the steps to start using it.

Code repository structure and contents

When your environment is ready, it is time to review the repository structure and its contents and review why we created it that way and how to use it.

Fig. 1 – Directory structure

The first file you should check is versions.tf. It contains the Harvester provider definition, which version we want to use and the required parameters. It also describes the Terraform version needed for the provider to work correctly.

Fig. 2 – versions.tf

The versions.tf file is also where you should provide the local path to the KubeConfig file you use to access Harvester. Please note that the release of the Harvester module might have changed over time; check the module documentation first and update it accordingly. In case you don’t know how to obtain the KubeConfig, you can download it easily from the UI in Harvester.

Fig. 3 – Download Harvester KubeConfig

At this point, I suggest checking the Harvester Terraform git repo and reviewing the example files before continuing. Part of the code you are going to find below comes from there.

The rest of the .tf files we are using could be merged into one single file since Terraform will parse them together. However, having separate files, or even folders, for all the different actions or components to be created is a good practice. It makes it easier to understand what Terraform will create.

The files variables.tf and terraform.tfvars are present in git as an example in case you want to develop or create your own repo and keep working with Terraform and Harvester. Most of the variables defined contain default values, so feel free to stick to them or provide your own in the tfvars file.

The following image shows all the files in my local repo and the ones Terraform created. I suggest rechecking the .gitignore file now that you understand better what to exclude.

Fig. 4 – Terraform repo files

The Terraform code

We first need an image or an ISO to provision a VM, which the VM will use as a base. In images.tf, we will set up the code to download an image for the VM and in variables.tf we’ll define the parameter values; in this case, an openSUSE cloud-init ready image in qcow2 format.

Fig. 5 – images.tf and variables.tf

Now it’s time to check networks.tf, which defines a standard Harvester network without further configuration. As I already had networks created in my Harvester lab, I’ll use a data block to reference the existing network; if a new network is needed, a resource block can be used instead.

Fig. 6 – network.tf and variables.tf

This is starting to look like something, isn’t it? But the most important part is still missing… Let’s analyze the vms.tf file.

There we define the VM that we want to create on Harvester and all that is needed to use the VM. In this case, we will also use cloud-init to perform the initial OS configuration, setting up some users and modifying the default user password.

Let’s review vms.tf file content. The first code block we find starts calling the harvester_virtualmachine function from the Terraform module. Using this function, we assign a name to this concrete instantiation as openSUSE-dev and define the name and tags for the VM we want to provision.

Fig. 7 – VM name

Note the depends_on block at the beginning of the virtual machine resource definition. As we have defined our image to be downloaded, that process may take some time. With that block, we instruct Terraform to put the VM creation on hold until the OS Image is downloaded and added to the Images Catalog within Harvester.

Right after this block, you can find the basic definition for the VM, like CPU, memory and hostname. Following it, we can see the definition of the network interface inside the VM and the network it should connect to.

Fig. 8 –CPU, memory, network definition and network variables

In the network_name parameter, we see how we call the module and the network defined in the networks.tf file. Please, remember that Harvester is based in KubeVirt and runs in Kubernetes, so all the standard namespace isolation rules apply here and that’s why a namespace attribute is needed for all the objects we’ll be creating (images, VMs, networks, etc.)

Now it’s time for storage. We define two disks, one for the OS image and one for empty storage. In the first one, we will use the image depicted in images.tf, and in the second one, we will create a standard virtio disk.

Fig. 9 – VM disks and disk variables

These disks will end up being Persistent Volumes in the Kubernetes cluster deployed inside a Storage Class defined in Longhorn.

Fig. 10 – Cloud-init configuration

Lastly, we find a cloud-init definition that will perform configurations in the OS once the VM is booted. There’s nothing new in this last block; it’s a standard cloud-init configuration.

The VM creation process

Once all the setup of the .tf files is done, it is time to run the Terraform commands. Remember to be in the path where all the files have been created before executing the commands. In case you are new to Terraform like I was, it is a good idea to investigate the documentation or go through the tutorials on the Hashicorp website before starting this step.

The first command is terraform init. This command will check the dependencies defined in versions.tf, download the necessary modules and review the syntaxis of the .tf files. If you receive no errors, you can continue creating an execution plan. The plan will be compared to the actual situation and to previous states, if any, to ensure that only the missing pieces compared with what we defined in the .tf files are created or modified as needed. Terraform, like other tools, use an idempotent approach, so we want to reach a concrete state.

My advice for creating the execution plan is to use the command terraform plan -out FILENAME so the plan will be recorded in that file, and you can review it. At this point, nothing has been created or modified yet. When the plan is ready, the last command will be terraform apply FILENAME; FILENAME is the plan file previously created. This command will start making all the changes defined in the plan. In this case, it downloads the OS image and then creates the VM.

Fig. 11 – Image download process

Fig. 12 – VM starting

Remember that I used an existing network, otherwise, creating a network resource would have been necessary. We wait for a couple of minutes, and voila! Our VM is up and running.

Fig. 13 – VM details

In the picture above, we can see that the VM is running and has an IP, the CPU and memory are as we defined and the OS image is the one specified in the images.tf file. Also, the VM has the tag defined in vms.tf and a label describing that the VM was provisioned using Terraform. Moving down to the Volumes tab, we’ll find the two disks we defined, created as PVs in the Kubernetes cluster.

Fig. 14 – VM volumes

Fig. 16 – VM disks (PVC)

Now the openSUSE VM is ready to use it!

Fig. 17 – openSUSE console screen

If you want to destroy what we have created, run terraform destroy. Terraform will show the list of all the resources that will be destroyed. Write yes to start the deletion process.

Summary

In this post, we have covered the basics of the Harvester Terraform provider. Hopefully, by now, you understand better how to use Terraform to manage Harvester, and you are ready to start making your own tests.

If you liked the post, please check the SUSE and Rancher blogs, the YouTube channel and SUSE & Rancher Community. There is a lot of content, classes and videos to improve your cloud native skills.

What’s Next:

Want to learn more about how Harvester and Rancher are helping enterprises modernize their stack speed? Sign up here to join our Global Online Meetup: Harvester on October 26th, 2022, at 11 AM EST.

Introduction

The effectiveness of good resource management in a secure and agile way is a challenge today. There are several solutions like Openstack and Harvester, which handles your hardware infrastructure as on-premise cloud infrastructure. This allows the management of storage, compute, and networking resources to be more flexible than deploying applications on single hardware only.

Both OpenStack and Harvester have their own use cases. This article describes the architecture, components, and differences between them to clarify what could be the best solution for every requirement.

This post analyzes the differences between OpenStack and Harvester from different perspectives: infrastructure management, resource management, deployment, and availability.

Cloud management is about managing data center resources, such as storage, compute, and networking. Openstack provides a way to manage these resources and a dashboard for administrators to handle the creation of virtual machines and other management tools for networking and storage layers.

While both Harvester and OpenStack are used to create cloud environments, there are several differences I will discuss.

According to the product documentation, OpenStack is a cloud operating system that controls large pools of compute, storage and networking resources throughout a data center. These are all managed through a dashboard that gives administrators control while empowering their users to provision resources through a web interface.

Harvester is the next generation of open source hyperconverged infrastructure (HCI) solutions designed for modern cloud native environments. Harvester also uses KubeVirt technology to provide cloud management with the advantages of Kubernetes. It helps operators consolidate and simplify their virtual machine workloads alongside Kubernetes clusters.

Architecture

While OpenStack provides its own services to create control planes and configures the infrastructure provided, Harvester uses the following technologies to provide the required stacks:

Harvester is installed as a node operating system using an ISO or a pxe-based installation, which uses RKE2 as a container orchestrator on top of SUSE Linux Enterprise Server to provide distributed storage with Longhorn and virtualization with Kubevirt.

APIs

Whether your environment is in production or in a lab setting, API use is far-reaching— for programmatic interactions, automations and new implementations.

Throughout each of its services, OpenStack provides several APIs for its functionality and provides storage, management, authentication and many other external features. As per the documentation, the logical architecture gives an overview of the API implementation.

In the diagram above, you can see the APIs a productive Openstack provides in bold.

Although OpenStack can be complex, it allows a high level of customization.

Harvester, in the meantime, uses Kubernetes for virtualization and Longhorn for storage, taking advantage of their APIs and allowing a high level of customization from the containerized architecture perspective. It can also be extended through the K8s CustomResourceDefinitions, which expands and migrates easier.

At the networking level, Harvester only supports VLAN through bridges and NIC bounding. Switches and advanced network configurations are outside the scope of Harvester.

OpenStack can provide multiple networking for advanced and specialized configurations.

Deployment

OpenStack provides several services on bare metal servers, such as installing packages and libraries, configuring files, and preparing servers to be added to OpenStack.

Harvester provides an ISO image preconfigured to be installed on bare metal servers.

Just install or pxe-install the image, and the node will be ready to join the cluster. This adds flexibility to scale nodes quickly and securely as needed.

Node types

OpenStack’s minimum architecture requirements consist of two nodes: a controller node to manage the resources and provide the required APIs and services to the environment and a compute node to host the resources created by the administrator. The controller nodes will maintain their roles supported in a production architecture.

Harvester nodes are interchangeable. It can be deployed in all-in-one mode, and the same node serving as a controller will act as compute node. This makes Harvester an excellent choice to consider for Edge architecture.

Cluster management

Harvester is fully integrated with Rancher, making adding and removing nodes easy. There is no need to preconfigure new compute nodes or handle the workloads since Rancher manages the cluster management.

Harvester can start in a single node (also known as all-in-one), where the node serves as a compute and a single node control plane. Longhorn, deployed as part of Harvester, provides the storage layer. When the cluster reaches three nodes, Harvester will reconfigure itself to provide High Availability features without disruption; the nodes can be promoted to the control plane or demoted as needed.

In OpenStack, roles (compute, controller, etc.) are locked since the node is being prepared to be added to the cluster.

Operations

Harvester leverages Rancher for authentication, authorization, and cluster management to handle the operation. Harvester integration with Rancher provides an intuitive dashboard UI where you can manage both at the same time.

Harvester also provides monitoring, managed with Rancher since the beginning. Users will see the metrics on the dashboard, shown below:

The dashboard also provides a single source of truth to the whole environment.

Storage

In Harvester, storage is provided by Longhorn as a service running on the compute nodes, so Longhorn scales easily with the rest of the cluster as new nodes are added. There is no need for extra nodes for storage. There is also no need to have external storage controllers to communicate between the control plane, compute, and storage nodes. Storage is distributed along the Harvester nodes from the view of the VMs (there is no local storage), and it also supports backups to NFS or S3 buckets.

Conclusion

Harvester is a modern, powerful cloud-based HCI solution based on Kubernetes, fully integrated with Rancher, that eases the deployment, scalability and operations.

While Harvester only supports NIC bounding and VLAN (bridge) methods, more networking modes will be added.

For more specialized network configurations, OpenStack is the preferred choice.

Want to know more?

Check out the resources!

• Harvester Product Page

• Getting Hands on with Harvester HCI

You can also check this in-depth SUSECON session delivered by my colleague Guang Yee:

Harvester is open source — if you want to contribute or check what is going on, visit the Harvester github repository

When I left Red Hat to join SUSE as a Technical Marketing Manager at the end of 2021, I heard about Harvester, a new Hyperconverged Infrastructure (HCI) solution with Kubernetes under the hood. When I started looking at it, I immediately saw use cases where Harvester could really help IT operators and DevOps engineers. There are solutions that offer similar capabilities but there’s nothing else on the market like Harvester. In this blog, I’ll give an overview of getting started with Harvester and what you need for a lab implementation.­

First, let me bring you up to speed on Harvester. This HCI solution from SUSE takes advantage of your existing hardware with cutting edge open source technology, and, as always with SUSE, offers flexibility and freedom without locking you in with expensive and complex solutions.

Figure 1 shows, at a glance, what Harvester is and the main technologies that compose it.

Fig. 1 – Harvester stack

The base of the solution is the Linux operating system. Longhorn provides lightweight and easy-to-use distributed block storage system for Kubernetes — in this case for the VMs running on the cluster. RKE2 provides the Kubernetes layer where KubeVirt runs, providing virtualization capabilities using KVM on Kubernetes. The concept is simple: like in Kubernetes, there are pods running in a cluster. The big difference is that there are VMs inside those pods.

To learn more about the tech under the hood and technical specs, check out this blog post from Sheng Yang introducing Harvester technical details.

The lab

I set up a home lab based on a Slimbook One node with an AMD Ryzen 7 processor, with 8 cores and 16 threads, 64GB of RAM and 1TB NVMe SSD — this is twice the minimum requirements for Harvester. In case you don’t know Slimbook, it is a brand focused on hardware oriented for Linux and open source software. You’ll need an ethernet connection for Harvester to boot, so if you don’t have a dedicated switch to connect your server, just connect it to the router from your ISV.

Fig. 2 – Slimbook One

The installation

The installation was smooth and easy since Harvester ships as an appliance. Download the ISO image and install it on a USB drive or use PXE for the startup. In this process, you’ll be asked some basic questions to configure Harvester during the installation process.

Fig. 3 – ISO Install

As part of the initial set up you can create a token that can be used later to add nodes to the cluster. Adding more nodes to the cluster is easy; you just start another node with the appliance and provide the token so the new node can join to the Kubernetes cluster. This is similar for what you do with RKE2 and K3s when adding nodes to a cluster. After you provide all the information for the installation process, you’ll have to wait approximately 10 minutes for Harvester to finish the set up. The Harvester configuration is stored as a yaml file and can be sourced from a URL during the installation to make the installation repeatable and easy to keep on a git repository.

Once the installation is finished, on the screen you’ll see the IP/DNS to connect Harvester and whether Harvester is ready or not. Once ready, you can log into the UI using the IP/DNS. The UI is very similar to Rancher and gives you the possibility to use a secure password in the first login.

Fig. 4 – Harvester installation finished & ready screen

The first login and dashboard

When you log in for the first time, you’ll see that it is easy to navigate.  Harvester benefits from a clean UI; it’s easy to use and completely oriented toward virtualization users and operators. Harvester offers the same kind of experience that IT operators would expect of a virtualization platform like oVirt.

Fig. 5 – Harvester dashboard

The first thing you’ll find once logged in is the dashboard, which allows you to see all the basic information about your cluster, like hosts, VMs, images, cluster metrics and VM metrics. If you navigate down the dashboard, you’ll find an event manager that shows you all the events segregated by kind of object.

When you dig further into the UI, you´ll find not only the traditional virtualization items but also Kubernetes options, like managing namespaces. When we investigate further, we find some namespaces are already created but we can create more in order to take advantage of Kubernetes isolation. Also, we find a fleet-local namespace which gives us a clue about how Kubernetes objects are managed inside the local cluster. Fleet is a GitOps-based deployment engine created by Rancher to simplify and improve cluster control. In the Rancher UI it’s referred to as ‘Continuous Deployment.’

Creating your first VM

Before creating your first VM you need to upload the image you’ll use to create it.  Harvester can use qcow2, raw and ISO images which can be uploaded from the Images tab using a URL or importing them from your local machine. Before uploading the images, you have the option to select which namespace you want them in, and you can assign labels (yes, Kubernetes labels!) to use them from the Kubernetes cluster. Once you have images uploaded you can create your first VM.

The VM assistant feels like any other virtualization platform out there: you select CPU, RAM, storage, networking options, etc.

Fig. 6 – VM creation

However, there are some subtle differences. First, you must select a namespace where to deploy the VM, and you have the possibility to see all the VM options as yaml code. This means your VMs can be defined as managed as code and integrated with Fleet. This is a real differentiator from more traditional virtualization platforms. Also, you can select the node where the VM will be running, use the Kubernetes scheduler to place the VM on the best node, apply scheduling rules or select specific nodes that do not support live migration. Finally, there is the option to use containers alongside VMs in the same pod; the container image you select is a sidecar for the VM. This sidecar container is added as a disk from the Harvester UI. Cloud config is supported out of the box to configure the VMs during the first launch as you could expect from solutions like OpenStack or oVirt.

Conclusion

Finding Kubernetes concepts on a virtualization solution might be a little awkward at the beginning. However, finding things like Grafana, namespace isolation and sidecar containers in combination with a virtualization platform really helps to get the best of both worlds. As far as use cases where Harvester can be of use, it is perfect for the Edge, where it takes advantage of the physical servers you already have in your organization since it doesn’t need a lot of resources to run. Another use case is as an on-prem HCI solution, offering a perfect way to integrate VMs and containers in one platform. The integration with Rancher offers even more capabilities. Rancher provides a unified management layer for hybrid cloud environments, offering central RBAC management for multi-tenancy support; a single pane of glass to manage VMs, containers and clusters; or deploying your Kubernetes clusters in Harvester or on most of the cloud providers in the market.

We may be in a cloud native world now, but VMs are not going anywhere. Solutions like Harvester ease the integration of both worlds, making your life easier.

To get started with Harvester, head over to the quick start documentation.

Join the SUSE & Rancher community to learn more about Harvester and other SUSE open source projects.

Polska premiera otwartej, interoperacyjnej infrastruktury hiperkonwergentnej (HCI). Zobacz jak Harvester unifikuje zarządzanie środowiskiem kontenerów i maszyn wirtualnych.

Zapraszamy na nasze pierwsze spotkanie z technologiami SUSE w 2022 roku, na którym zaprezentujemy Harvestera. To otwarte, interoperacyjne i rewolucyjne rozwiązanie HCI oparte na Kubernetesie. Od naszch inżynierów dowiesz się, jak Harvester i SUSE Rancher mogą pomóc Twojej organizacji zmodernizować stos wykorzystywanych technologii IT i rozwiązać problem złożoności infrastruktury informatycznej w przypadku stosowania zwirtualizowanych i skonteneryzowanych obciążeń.

W programie spotkania

• Dlaczego SUSE weszła w obszar infrastruktury hiperkonwergentnej,
• Jak przebiega integracja pomiędzy rozwiązaniami SUSE Rancher i Harvester,
• Co zapewni działowi operacji skonsolidowanie obciążeń zwirtualizowanych i skonteneryzowanych,
• Pokaz na żywo możliwości Harvestera,
• Pytania i odpowiedzi na żywo oraz omówienie planów rozwoju Harvestera.

Dołącz do nas 19 stycznia o 10:00!

Spotkanie 19 stycznia poprowadzą w jęz. polskim inżynierowie SUSE Rancher, Jarosław Bieniek i Jarek Śliwiński za pomocą platformy webinarowej ON24. Do udziału w nim wystarczy przeglądarka internetowa, nie ma konieczności instalowania dodatkowego oprogramowania. Na podany podczas rejestracji adres email wyślemy pocztą indywidualny link do udziału.

Rejestracja na spotkanie: https://more.suse.com/Harvester_Meetup_Registration_PL

Cloud platforms are not new — they have been around for a few years. And containers have been around even longer. Together, they have changed the way we think about software. Since the creation of these technologies, we have focused on platforms and apps. And who could blame anyone? Containers and Kubernetes let us do things that were unheard of only a few years ago.

What about the software that runs the infrastructure to support all these advancements? Over the same time, we have seen advancements — some in open source but the most with proprietary solutions. Sure, there is nothing wrong with running open source on top of a proprietary solution. These systems have become very good at what they do: running virtual machines but not container or container platforms, for that matter.

The vast majority of this infrastructure software is proprietary. This means you need two different skill sets to manage each of these — one proprietary, one Kubernetes. This is a lot to put on one team; it’s almost unbearable to put on one individual. What if there was an open infrastructure that used the same concepts and management plane as Kubernetes? We could lower the learning curve by managing our clusters the same way we can manage our host. We trust Kubernetes to manage clusters — why not our hosts?

Harvester: Built on Open Cloud Native Technology

Harvester is a simple, elegant, and light hyperconverged infrastructure (HCI) solution built for running virtual machines and Kubernetes clusters on bare metal servers. With Harvester reaching General Availability, we can now manage our host with the same concepts and management plane as our clusters. Harvester is a modern infrastructure for a modern platform. Completely open source, this solution is built on Kubernetes and incorporates other cloud native solutions, including Longhorn and Kubevirt, and leveraging all of these technologies transparently to deliver a modern hypervisor. This gives Harvester endless possibilities with all the other projects that integrate with Kubernetes.

This means operators and infrastructure engineers can leverage their existing skill sets and will find in Harvester a familiar HCI experience. Harvester easily integrates into cloud native environments, and offers enterprise-grade, turnkey features without costly overhead of the proprietary alternatives — saving both time and money.

A Platform for the Edge

Harvester’s small footprint means it is a great choice for the unique demands of hardware at the edge. Harvester gives operators the ability to deploy and manage VMs and Kubernetes clusters on a single platform. And because it integrates into Rancher, Harvester clusters can be managed centrally using all the great tooling Rancher provides. Edge applications will also benefit from readily available enterprise-grade storage, without costly and specialized storage hardware required. This enables operators to keep compute and storage as close to the user as possible, without sacrificing management and security. Kubernetes is quickly becoming a standard for edge deployments, so an HCI that also speaks this language is beneficial.

Harvester is a great solution for data centers, which come in all shapes and sizes. Harvester’s fully integrated approach means you can use high-density hardware with low-cost local storage. This saves on equipment costs and the amount of rack space required. A Harvester cluster can be as small as three servers, or an entire rack. Yet it can run just as well in branch or small-office server rooms. And all of these locations can be centrally managed through Rancher.

A Platform for Modernizing Applications

Harvester isn’t just a platform for building cloud native applications but one that you can use to take applications from VMs to clusters. It allows operators to run VMs alongside clusters, giving developers the opportunity to start decomposing these monoliths to cloud native applications. With most applications, this takes months and sometimes years. With Harvester, there isn’t a rush. VMs and clusters live side by side with ease. It offers all of this in one platform with one management plane.

As cloud native technologies continue their trajectory as keys to digital transformation, next-gen HCI solutions need to offer functionality and simplicity with the capability to manage containerized and non-containerized workloads, storage and network requirements across any environment.

Conclusion

What’s unique about Harvester? You can use it to manage multiple clusters hosted on VMs or a Kubernetes distribution. It’s 100 percent open source and leverages proven technologies – so why not give it a try to simplify your infrastructure stack?  You’ll get a feature-rich operational experience in a single management platform, with the support of the open-source community behind it. We have seen the evolution of Harvester, from a fledgling open-source project to a full-on enterprise-ready HCI solution.

We hope you take a moment to download and give Harvester a try.

JOIN US at the Harvester Global Online Meetup – January  19 at 10am PT. Our product team will be on hand to answer your questions. Register here.

Thousands of new technology solutions are created each year, all designed to help serve the open source community of developers and engineers who build better applications. In 2014, Rancher was founded as a software solution aiming to help simplify the lives of engineers building applications in the new market of containers.

Today, Rancher is a market-leading, open source solution supported by a rich community helping thousands of global organizations deliver Kubernetes at scale.

Harvester is a new project from the SUSE Rancher team. It is a 100% open source, Hyperconverged Infrastructure (HCI) solution that offers the same expected integrations as traditional commercial solutions while also incorporating beneficial components of Kubernetes. Harvester is built on a foundation of cloud native technology to bridge the gap between traditional HCI and cloud native solutions.

Why Is This Significant?

Harvester addresses the intersection of traditional HCI frameworks and modern containerization strategies. Developed by SUSE’s team of Rancher engineers, Harvester preserves the core values of Rancher. This includes enriching the open source community by creating Harvester as a 100% open, interoperable, and reliable HCI solution that fits any environment while retaining the traditional functions of HCI solutions. This helps users efficiently manage and operate their virtual machine workloads.

When Harvester is used with Rancher, it provides cloud native users with a holistic platform to manage new cloud native environments, including Kubernetes and containers alongside legacy Virtual Machine (VM) workloads. Rancher and Harvester together can help organizations modernize their IT environment by simplifying the operations and management of workloads across their infrastructure, reducing the amount of operational debt.

What Can We Expect in the Rancher & Harvester Integration?

There are a couple of significant updates in this v0.3.0 of Harvester with Rancher. The integration with Rancher v2.6.1 gives users extended usability across both platforms, including importing and managing multiple Harvester clusters using the Virtualization Management feature in Rancher v2.6.1. In addition, users can also leverage the authentication mechanisms and RBAC control for multi-tenancy support available in Rancher.

Harvester users can now provision RKE & RKE2 clusters within Rancher v2.6.1 using the built-in Harvester Node Driver. Additionally, Harvester can now provide built-in Load Balancer support and raw cluster persistent storage support to guest Kubernetes clusters.

Harvester remains on track to hit its general availability v1.0.0 release later this year.

Learn more about the Rancher and Harvester integration here.

You can also check out additional feature releases in v0.3.0 of Harvester on GitHub or at harvesterhci.io.

What I liked about the release of Harvester 0.2.0 was the ease of enabling the embedded Rancher server, which allowed you to create Kubernetes clusters in the same Harvester cluster.

With the release of Harvester 0.3.0, this option was removed in favor of installing Rancher 2.6.1 separately and then importing your Harvester cluster into Rancher, where you could manage it. A Harvester node driver is provided with Rancher 2.6.1 to allow you to create Kubernetes clusters in the same Harvester 0.3.0 cluster.

I replicated my Harvester 0.2.0 plus the Rancher server experience using Harvester 0.3.0 and Rancher 2.6.1.

There’s no upgrade path from Harvester 0.2.0 to 0.3.0, so the first step was reinstalling my Intel NUC with Harvester 0.3.0 following the docs at: https://docs.harvesterhci.io/v0.3/install/iso-install/.

Given that my previous Harvester 0.2.0 install included Rancher, I figured I’d install Rancher in a VM running on my newly installed Harvester 0.3.0 node – but which OS would I use? With Rancher being deployed using a single Docker container, I was looking for a small, lightweight OS that included Docker. From past experience, I knew that openSUSE Leap had slimmed down images of its distribution available at https://get.opensuse.org/leap/ – click the alternative downloads link immediately under the initial downloads. Known as Just enough OS (JeOS), these are available for both Leap and Tumbleweed (their rolling release). I opted for Leap, so I created an image using the URL for the OpenStack Cloud image (trust me – the KVM and XEN image hangs on boot).

Knowing that I wanted to be able to access Rancher on the same network my Harvester node was attached to, I also enabled  Advanced | Settings | vlan (VLAN) and created a network using VLAN ID 1 (Advanced | Networks).

The next step is to install Rancher in a VM. While I could do this manually, I prefer automation and wanted to do something I could reliably repeat (something I did a lot while getting this working) and perhaps adapt when installing future versions. When creating a virtual machine, I was intrigued by the user data and network data sections in the advanced options tab, referenced in the docs at https://docs.harvesterhci.io/v0.3/vm/create-vm/, along with some basic examples. I knew from past experience that cloud-init could be used to initialize cloud instances, and with the openSUSE OpenStack Cloud images using cloud-init, I wondered if this could be used here. According to the examples in the cloud-init docs at https://cloudinit.readthedocs.io/en/latest/topics/examples.html, it can!

When creating the Rancher VM, I gave it 1 CPU with a 4-core NUC and Harvester 0.3.0 not supporting over-provisioning (it’s a bug – phew!) – I had to be frugal! Through trial and error, I also found that the minimum memory required for Rancher to work is 3 GB. I chose my openSUSE Leap 15.3 JeOS OpenStack Cloud image on the volumes tab, and on the networks tab, I chose my custom (VLAN 1) network.

The real work is done on the advanced options tab. I already knew JeOS didn’t include Docker, so that would need to be installed before I could launch the Docker container for Rancher. I also knew the keyboard wasn’t set up for me in the UK, so I wanted to fix that too. Plus, I’d like a message to indicate it was ready to use. I came up with the following User Data:

password: changeme
packages:
  - docker
runcmd:
  - localectl set-keymap uk
  - systemctl enable --now docker
  - docker run --name=rancher -d --restart=unless-stopped -p 80:80 -p 443:443 --privileged rancher/rancher:v2.6.1
  - until curl -sk https://127.0.0.1 -o /dev/null; do sleep 30s; done
final_message: Rancher is ready!

Let me go through the above lines:

• Line 1 sets the password of the default opensuse user – you will be prompted to change this the first time you log in as this user, so don’t set it to anything secret!
• Lines 2 & 3 install the docker package.
• Line 4 says we’ll run some commands once it’s booted the first time.
• Line 5 sets the UK keyboard.
• Line 6 enables and starts the Docker service.
• Line 7 pulls and runs the Docker container for Rancher 2.6.1 – this is the same line as the Harvester docs, except I’ve added “–name=rancher” to make it easier when you need to find the Bootstrap Password later.
  NOTE: When you create the VM, this line will be split into two lines with an additional preceding line with “>-” – it will look a bit different, but it’s nothing to worry about!
• Line 8 is a loop checking for the Rancher server to become available – I test localhost, so it works regardless of the assigned IP address.
• Line 9 prints out a message saying it’s finished (which happens after the previous loop completes).

An extra couple of lines will be automatically added when you click the create button but don’t click it yet as we’re not done!

This still left a problem with which IP address I use to access Rancher? With devices being assigned random IP addresses via DHCP, how do I control which address is used? Fortunately, the Network Data sections allow us to set a static address (and not have to mess with config files or run custom scripting within the VM):

network:
  version: 1
  config:
    - type: physical
      name: eth0
      subnets:
        - type: static
          address: 192.168.144.190/24
          gateway: 192.168.144.254
    - type: nameserver
      address:
        - 192.168.144.254
      search:
        - example.com

I won’t go through all the lines above but will call out those you need to change for your own network:

• Line 8 sets the IP address to use with the CIDR netmask (/24 means 255.255.255.0).
• Line 9 sets the default gateway.
• Line 12 sets the default DNS nameserver.
• Line 14 sets the default DNS search domain.

See https://cloudinit.readthedocs.io/en/latest/topics/network-config-format-v1.html# for information on the other lines.

Unless you unticked the start virtual machine on creation, your VM should start booting once you click the Create button. If you open the Web Console in VNC, you’ll be able to keep an eye on the progress of your VM. When you see the message Rancher is ready, you can try accessing Rancher in a web browser at the IP address you specified above. Depending on the web browser you’re using and its configuration, you may see warning messages about the self-signed certificate Rancher is using.

The first time you log in to Rancher, you will be prompted for the random bootstrap password which was generated. To get this, you can SSH as the opensuse user to your Rancher VM, then run:

sudo docker logs rancher 2>&1 | grep "Bootstrap Password:"

Copy the password and paste it into the password field of the Rancher login screen, then click the login with Local User button.

You’re then prompted to set a password for the default admin user. Unless you can remember random strings or use a password manager, I’d set a specific password. You also need to agree to the terms and conditions for using Rancher!

Finally, you’re logged into Rancher, but we’re not entirely done yet as we need to add our Harvester cluster. To do this, click on the hamburger menu and then the Virtualization Management tab. Don’t panic if you see a failed whale error – just try reloading.

Clicking the Import Existing button will give you some registration commands to run on one of your Harvester node(s).

To do this, SSH to your Harvester node as the rancher user and then run the first kubectl command prefixed with sudo. Unless you’ve changed your Harvester installation, you’ll also need to run the curl command, again prefixing the kubectl command with sudo. The webpage should refresh, showing your Harvester cluster’s management page. If you click the Harvester Cluster link or tab, your Harvester cluster should be listed. Clicking on your cluster name should show something familiar!

Finally, we need to activate the Harvester node driver by clicking the hamburger menu and then the Cluster Management tab. Click Drivers, then Node Drivers, find Harvester in the list, and click Activate.

Now we have Harvester 0.3.0 integrated with Rancher 2.6.1, running similarly to Harvester 0.2.0, although sacrificing 1 CPU (which will be less of an issue once the CPU over-provisioning bug is fixed) and 3GB RAM.

Admittedly, running Rancher within a VM in the same Harvester you’re managing through Rancher doesn’t seem like the best plan, and you wouldn’t do it in production, but for the home lab, it’s fine. Just remember not to chop off the branch you’re standing on!
